GLIAL EIC32/EIC53
The GLIAL EIC32/53 electric version of the GLIAL TTO has a wider range of usage scenarios without using a compressor as the power source for the print head and is especially suitable for embedded applications such as in Food & Pharmaceutical dispensers.
Features
- 8" multi-touch capacitive screen for human-machine interaction
- Software is made on Android, similar to mobile phones
- Controller with built-in power module
- Image/logo, Barcode & QR creation created in free designer software
- Clip-on ribbon cartridge for quick and easy ribbon loading
- Automatic ribbon recognition ensuring print quality
- Automatic detection of ribbon tension and ribbon length
- Automatic speed adjustment deduction and align
- Ultra high precision print quality
- High Speed printing upto 260ppm
- Gap between print is 0.5mm
- Electromagnetically driven lift head ribbon saving design
- Task/Job Add/Edit can be achieved on control unit itself
- Multilingual fonts supported
- Multiple print triggers
- Optional intermittent & continuous printing modes
- Automatic detection of bad print point
- Print date codes, batch numbers, 1D and 2D barcodes
High reliability
Efficient printing
Energy efficient
environmentally friendly
Specification
| Model Name | EIC32 | EIC53 |
|---|---|---|
| Structure | All-metal structure | |
| Print Method | Thermal transfer printing | |
| Film Movement | Left | |
| TPH Movement | Continuous & Intermittent | |
| Max Print Width | 32mm (300DPI) | 53mm (300DPI) |
| Print Length | 100mm | 55mm |
| Resolution | 300DPI (12dots/mm) | |
| Print Speed | 50mm/s-400mm/s – 260ppm | |
| Real-time Clock | STD | |
| Sensor | Ribbon tension sensor; TPH position sensor; cover opening sensor; TPH over temperature sensor; ribbon break sensor | |
| Package Sensor | Electromagnetic induction, synchronizers (continuous models), photoelectric sensors, proximity switches | |
| Package Material | PVDC/PET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, PE, VMPET, VMCPP and other films | |
| Ribbon length | Wax Resin 600m & Resin 600m | |
| Ribbon Type | Resin / Resin-Wax | |
| USB Host | USB2.0 | |
| Ethernet Interface | D89 interface | |
| Power Supply | Internal switching power supply module AC90V-264V, 47/63 Hz; 150VA | |
| Software | Format Designer | |
| Conditions | Operation: 0-40°C humidity 10%-90% non-condensing | |
| Machine Dimension |
Controller (L*H*W): 226.3 × 141.5 × 183.28 Printer (L*H*W): 210.65 × 184 × 229.65 |
|
